Internal 16 port RS232/422/485 PCIe Card 3KV Isolation 4KV Surge 15KV ESD protection
Item number SERPE-T3160i
Diarts designs embedded internal Serial PCI Express Card, why is ” Internal Serial Card “.
As we know when use 2 or 4 or 8 or 16 ports serial RS232 RS422 RS485 Addon Card. Always needs to have a Serial RS232/422/485 fanout cable. PC case looks mess, because of fanout cable. That is why diarts works on the Serial RS232/422/485 Card into Internal the PC case. After instill internal RS232 RS422 RS485 Card. The PC case looks more clear and do not worry the cable will loose. Then all PC looks more strong.
How the Internal Serial Card work, It has a main board, and child boards. Between main board and child board has a cable to link. Each child board has 4 port RS232 RS422 RS485 with 3KV Isolation 4KV Surge 15KV ESD protection. You can select Serial RS232 or RS422 or RS485 mode on child board.
How to fixed embedded Internal 16 port RS232/422/485 PCIe Card in PC. The main board, it will instill on PCIe slot, and use bracket to fixed with PC case. The embedded internal child board, it is using DB9M to fixed with PC case. That is strong. And the PC case is looks clear and without mess.
With Embedded Internal Serial RS232 RS422 RS485 PCI Express Card designs it supports RS232 only, RS232 3KV Isolation 4 KV Surge, and RS232/422/485 3KV Isolation 4KV Surge. We have supports with 2 ports, 4 ports, 8 ports, and 16 ports. It will depend on how many ports you need.
Features and Benefit
Expands 16 com ports for your system
High Speed Baud Rate up to 921.6Kbps
Design to meet PCI Express 2.0 Gen 1 compliant
Supports PCI Express x1, x2, x4, x8, and x16 Lane
3KV Isolation protection
4KV Surge Protection
Built-in 15KV ESD protection
Supports Industrial Specification
256 byte FIFOs
Supports Microsoft Windows, Linux, and QNX drivers
Specification
Hardware
Communication controller: 16C550 UART Compatible register Set
Bus: PCI Express x 1
Serial Interface
Number of ports: 16 ports
Serial Standard: RS-232 RS422 RS485
IRQ and I/O Address: Assigned by System
Serial Line Protection
Isolation: 3KV Isolation protect
Surge: 4KV protection
ESD Protection: 15KV ESD Protection for all signals
Performance
Baud rate: up to 921.6 Kbps
FIFOs: 256 byte
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Serial Signals
RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND. RI
RS-422: TxD+, TxD- RxD+, RxD-, GND
2 Wire RS-485: Data+, Data-, GND
4 Wire RS-485: TxD+, TxD-, RxD+, RxD-, GND
Driver Support
Windows: XP, 2003, Vista, 2008, Win 7, Windows 10
Linux: 2.6, 3.0
QNX: 6.0
Physical Characteristics
Bracket: Standard Bracket
Bracket Space: 1
Environmental Limits
Operating Temperature: -30 ~ 75℃
Storage Temperature: -40 ~ 85℃
Ambient Relative Humidity: 5 ~ 95% Non-Condensing
Standards and Certifications
CE and FCC supports
Product Production
Production: Made in Taiwan
Product Location: Taipei, Taiwan
Package Content
16 port PCI Express Card x 1
4 port RS232/422/485 3KV Isolation 4KV Surge 15KV ESD Adapter x 4
Quick Instill Guide x 1
Driver CD x 1
