Description
Industrial 2 port High Speed Serial RS-232 + 1 port Parallel Universal PCI card support 5V/12V/RI Selectable and Standard and Low Profile Bracket
Item Number: MIOP-1211PDB44F
Features and Benefit
Expands 2 com ports RS232 for your system
High Speed Baud Rate up to 921.6Kbps
Compatible with 3.3V/5V PCI and PCI-x slot
Power Supply through communication line(RI signal)
Built-in 15KV ESD protection
Supports Industrial Specification
256 byte FIFOs integrated UART
Supports 5V/12V/RI Selectable
Parallel – Compatibility mode, Nibble mode, Byte mode, EPP mode, and ECP mode)
16byte : EPP/ECP mode
I/O Address remap – RS-232 for 3F8, 2F8, 3E8, AND 2E8. Parallel – 378 and 278
Supports Microsoft Windows 10, Linux
Specification
Hardware
Communication controller: 16C550 UART Compatible register Set
Bus: 32 bit Universal PCI 64/32bit 3.3V/5V PCI ver 3.0, 2.3, 2.2, 2.1 and PCI-X
Connector: DB44F x 1
Interface
Number of ports: 3 ports
Serial Standard: RS-232 x2
Parallel: Parallel x 1
IRQ and I/O Address: Assigned by System or Remap function I/O Address RS-232 for 3F8, 2F8, 3E8, and 2E8. Also supports remap function for Parallel for 378 and 278.
Serial Line Protection
ESD Protection: 15KV ESD Protection for all signals
Performance
Baud rate: up to 921.6 Kbps
FIFOs: 256 byte
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF
Parallel
IEEE Standard 1284 Protocols(compatibility Mode, Nibble Mode, Byte Mode, EPP Mode, and ECP Mode)
16byte EPP/ECP Mode
Serial Signals
RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND, 5V/12V/RI(selectable)
Driver Support
Windows: XP, 2003, Vista, 2008, Win 7
Linux: 2.4 and 2.6
Physical Characteristics
Bracket: Standard and Low Profile Bracket
Bracket Space: 1
Environmental Limits
Operating Temperature: -30 ~ 75℃
Storage Temperature: -40 ~ 85℃
Ambient Relative Humidity: 5 ~ 95% Non-Condensing
Standards and Certifications
CE and FCC supports
Product Production
Production: Made in Taiwan
Product Location: Taipei, Taiwan
Package Content
2 port RS-232 + 1 port Parallel PCI Card x 1
DB44F to DB9M x 2 + DB25F x 1 Cable 30cm x 1
Low Profile Bracket x 1
Quick Instill Guide x 1
Driver CD x 1
