Wireless RS422 RS485 Isolation Device Server

Wireless 802.11 b/g

Gateway IP Address

Serial RS-422/485 Interface 2 port

3KV Optical Isolation

600W Surge protection

10/100 Mbps Ethernet Interface

Transfer Rate up to 921Kbps

Two Power Supplies way, both support 10 – 48V

Supports Mode: VSP Com, TCP Server, TCP Client, UDP, Paired Mode,        HTTP, DHCP, ICMP(Ping), Static IP, and ARP Supported

Spread Spectrum Technology:  DSSS, OFDM, DBPSK, DQPSK, CCK, 16-QAM, 64-QAM

Tx Power 11b:  Maximum 15dBm +/-1.5 dBm

Tx Power 11g:  Maximum 12dBm +/- 1.5dBm

Transmission distance:  Up to 200 meters ( @12 Mbps, in open areas )

Antenna Connector:  SMD Coaxial Connector , 2 dBi Antenna

Supports Industrial Specification


Description

Product Description: Wireless to 2 port RS-422/485 + 3KV Isolation + 600W Surge protection Device Server

Item Number: SERWLA-2020i



Features and Benefit

Wireless 802.11 b/g

Gateway IP Address

Serial RS-422/485 Interface 2 port

3KV Optical Isolation

600W Surge protection

10/100 Mbps Ethernet Interface

Transfer Rate up to 921Kbps

Two Power Supplies way, both support 10 – 48V

Supports Mode: VSP Com, TCP Server, TCP Client, UDP, Paired Mode,        HTTP, DHCP, ICMP(Ping), Static IP, and ARP Supported

Spread Spectrum Technology:  DSSS, OFDM, DBPSK, DQPSK, CCK, 16-QAM, 64-QAM

Tx Power 11b:  Maximum 15dBm +/-1.5 dBm

Tx Power 11g:  Maximum 12dBm +/- 1.5dBm

Transmission distance:  Up to 200 meters ( @12 Mbps, in open areas )

Antenna Connector:  SMD Coaxial Connector , 2 dBi Antenna

Supports Industrial Specification



Specification

Hardware

Serial Connector: Terminal Block 5 pin x 2

Ethernet port: RJ 45 x 1

Wireless port – 802.11 b/g

Power port: DC Jack x 1 and Terminal Block 3 pin x 1



Serial Interface

RS-422/485 ports: 2 ports



Serial Line Protection

ESD Protection: 15KV ESD Protection for all signals

Optical Isolation Protection: 3KV Opto Isolator Protection for each port

Surge Protection” 600W Surge Protection for RS-422/485 Signals





Performance

Baud rate: up to 921 Kbps



Serial Communication Parameters

Data Bits: 7, 8

Stop Bits: 1, 2

Parity: None, Even, Odd, Space, Mark



Connector Signals

RS-422: TxD+, TxD- RxD+, RxD-, GND

2 Wire RS-485: Data+, Data-, GND

4 Wire RS-485: TxD+, TxD-, RxD+, RxD-, GND



DIP Switch

RS-422: Terminator Resistor Setting

RS-485 Terminator Resistor Setting

RS-485 Echo/non – Echo Selection

RS-422/485 Selection



VSP com Support

Windows 2000, 2003, XP, 2008, Vista Win 7 32 and 64bit



Environmental Limits

Operating Temperature: -10 ~ 60℃

Storage Temperature: -40 ~ 85℃

Ambient Relative Humidity: 5 ~ 95% Non-Condensing



Standards and Certifications

CE and FCC supports



Product Production

Production: Made in Taiwan

Product Location: Taipei, Taiwan



Package Content

2 port RS-422/485 Isolation Devcie Server WiFi x 1

12V1A Power Adapter(option)

Quick Instill Guide x 1

Driver CD x 1
