Description

3 port External + 1 port Internal Super-Speed USB3.0 PCIe Card support Standard and Low Profile Bracket

Item Number: UPD720201-PE31

Features and Benefit

Expands 3 port External + 1 port Internal for your system

High Speed Transfer Rate up to 5Gbs

Design to meet PCI Express 2.0 Gen 1 compliant

PCI Express x1, x2, x4, x8, and x16 Lane

Universal Serial Bus 3.0 Specification Revision 1.0

Compliant with xHCI(eXtensible Host Controller Interface) Specifications Revision 0.96

simultaneous operation of multiple USB 3.0, USB 2.0, and USB 1.1 devices

USB Data transfer rate of 1.5/12/480/5000 Mbps

Expands 3 port External + 1 port Internal USB3.0 Super-Speed Port for your Desktop system

Each USB port output power up to 5V 900ma for USB device

Hot Swap feature allow you to connect/disconnect devices

Microsoft WHQL approve

Supports Driver for Microsoft Windows 10

Specification

Hardware

Communication controller: USB3.0 chipset

Bus: PCI Express x 1

Connector: USB 3.0 A type x 3, and USB3.0 A type x1 Internal USB3.0 port

Interface

Number of ports: 3 port External + 1 port Internal

USB Standard: USB 3.0(Low Speed (1.5Mbps), Full Speed(12Mbps), High Speed(480Mbps), Super Speed(5Gpbs) )

Performance

Data transfer rate: 1.5/12/480/5000 Mbps

PCIe Card Power Input

Input: Molex 4 Pin Power Connector

USB3.0 Power Out

USB 3.0: 5V/900ma(each port)

Driver Support

Windows: XP, Vista, Win 7/8(32 and 64bit)

Physical Characteristics

Bracket: Standard and Low Profile Bracket

Bracket Space: 1

Standards and Certifications

CE and FCC supports

Product Production

Production: Made in Taiwan

Product Location: Taipei, Taiwan

Package Content

3 port External + 1 port Internal Super-Speed USB3.0 PCIe Card x 1

Low Profile Bracket x 1

Quick Instill Guide x 1

Driver CD x 1

Warranty

Warranty Period: 1 Year
